102.HQ-N10(PULACE)

Categories: Brands, Burgmann Replacements, Multi-Spring Seals, Standard Mechanical Seals, Structure

Type：	Multi Spring Seal
Replacement：	Bergmann PULACE
Temperature：	-20℃ to +200℃
Pressure：	≤1.0Mpa
Speed：	≤20m/s
Material：	B,A1,Q1,Q2,U2,P,E,N,V,F,G

Product descripton

d (mm)	D1	D2	D3	L	L1
20	51	46	57	71	34
25	58	51	64	71	34
30	63	56	69	71	34
35	68	62	74	75	37
40	76	69	82	80	38
45	83	78	89	80	38
50	86	78	92	80	38
55	92	86	98	80	38
60	98	91	104	78	37
65	102	97	108	81	38
70	109	102	115	80	38
75	114	107	120	82	39
80	119	112	125	82	40
85	124	118	130	85	40
90	137	126	143	85	42
95	137	126	143	85	42
100	144	135	150	85	42
