133.HQN3X-D

Categories: Brands, Fluiten Replacements, Multi-Spring Seals, Standard Mechanical Seals, Structure

Type：	Muti-Spring Double Mechanical seal for Boerger series pumps
Replacement：	Fluiten N3X-N3X
Temperature：	-100 to 250℃
Pressure：	≤12.0 Bar
Speed：	≤20 m/s
Material：	B,A1,Q1,Q2,U2,P,E,N,V,F,G,Alfa

Product descripton

d	D1	D2	D3	d8	L1	L3	L4
(mm)	H11	H8	D3	d8	L1	L3	L4
105	120.5	129	137	4	118	80	19
110	125.5	134	142	4	118	80	19
115	130.5	139	147	4	118	80	19
120	135.5	144	152	4	118	80	19
125	140.5	149	157	4	118	80	19
130	145.5	154	162	4	118	80	19
140	154.5	166	172	4	124	85	22
150	171.5	183	190	5	137	94	26
160	181.5	193	200	5	146	94	26
170	191.5	203	210	5	146	94	26
180	201.5	213	220	5	146	94	26
190	211.5	223	230	5	146	94	26
200	221.5	233	240	5	146	94	26
