287.HQSC-J30(1648)

Categories: Brands, Cartridge Seals, Crane Replacements

Type：	Single Cartridge Seal
Replacement：	Crane 1648
Temperature：	-40℃ to +260℃
Pressure：	≤6.9Mpa
Speed：	≤25m/s
Material：	Q1,Q2,U2,T,V,M1,F,G,M

Product descripton

d(inch)	D1	D2	L	L1	L2
d(inch)	D1	D2	L	L1	L2
1.000	2.125	2.500	5.75	3.812	2.562
1.125	2.375	2.750	5.75	4.125	2.562
1.250	2.500	2.875	5.75	4.125	2.562
1.375	2.625	3.000	5.75	4.125	2.562
1.500	2.750	3.125	5.75	4.125	2.562
1.625	3.000	3.375	5.75	4.437	2.562
1.750	3.125	3.500	5.75	4.437	2.562
1.875	3.250	3.625	5.75	4.437	2.562
2.000	3.375	3.750	6.50	4.437	2.562
2.125	3.500	3.875	6.50	4.437	2.562
2.250	3.625	4.000	6.50	4.437	2.625
2.375	3.750	4.125	6.50	4.500	2.625
2.500	3.812	4.187	6.50	4.500	2.625
2.625	3.937	4.312	6.50	4.500	2.625
2.750	4.125	4.500	6.50	4.500	2.781
2.875	4.250	4.625	6.50	4.656	2.781
3.000	4.375	4.750	6.50	4.656	2.781
3.125	4.500	4.875	7.00	4.656	2.781
3.250	4.625	5.000	7.00	4.656	2.781
3.375	4.750	5.125	7.00	4.656	2.781
3.500	4.875	5.250	7.00	4.656	2.781
3.625	5.125	5.500	7.00	4.656	2.781
3.750	5.250	5.625	7.00	4.656	2.781
3.875	5.375	5.750	7.00	4.656	2.781
4.000	5.500	5.875	7.00	4.656	2.781
4.125	5.625	6.000	7.00	4.656	2.781
4.250	5.750	6.125	7.00	4.656	2.781
