558.HQK-03(204B)

Categories: Chinese Standard, Kettle Pump Seals

Type：	Kettle Seal
Replacement：	Small spring,end suface,balanced mechanical seal
Temperature：	-40℃ to +180℃
Pressure：	≤0.8Mpa
Speed：	≤500rpm
Material：	Q1,Q2,A,B,U1,U2,P,E,V,T,F,G,T2,M5

Product descripton

d (mm)	D1	D2	D3	D4	D5	H	n-￠
30	50	116	150	185	67	16	4-￠18
35	60	116	150	185	72	16	4-￠18
40	64	135	170	205	77	16	4-￠18
50	74	164	200	235	87	16	8-￠18
60	85	164	200	235	103	16	8-￠18
65	91	164	200	235	103	16	8-￠18
70	97	164	200	235	108	16	8-￠18
80	110	188	225	260	118	16	12-￠18
90	119	220	255	290	128	16	12-￠18
95	123	220	255	290	133	16	12-￠18
100	132	245	280	315	198	16	12-￠18
110	140	245	280	315	148	16	12-￠18
120	158	245	280	315	158	21	12-￠18
130	168	245	280	315	168	22	12-￠18
140	180	245	280	315	178	22	12-￠18
1450	190	285	320	360	188	22	12-￠18
160	200	285	320	360	198	25	12-￠18
180	220	285	320	360	218	25	12-￠18
