65.HQ1523/HQ1524

Categories: Brands, Chinese Standard, O-Ring Seals, Other Seals, Standard Mechanical Seals, Structure

Type：	O-Ring Mechanical Seal
Replacement：	Widely used for industrial pumps
Temperature：	-20 to 180℃
Pressure：	≤3Mpa
Speed：	≤15m/s
Material：	B,A1,Q1,Q2,U2,P,E,N,V,F,G,Alfa

Product descripton

HQ1523

HQ1524

d (mm)	d0	D1	D2	D3	D4 (min)	L1	L2
d (mm)	d0	D1	D2	D3	D4 (min)	L1	L2
18	22	33	27	36	38	55	20
20	24	35	29	38	40	60	20
22	26	37	31	40	42	60	20
24	28	39	33	42	44	60	20
25	30	40	34	44	46	60	20
28	33	43	37	47	49	65	20
30	35	45	39	49	51	65	20
32	38	48	42	54	58	65	20
33	38	48	42	54	58	65	20
35	40	50	44	56	60	65	20
38	43	56	49	59	63	75	23
40	45	58	51	61	65	75	23
43	48	61	54	64	68	75	23
45	50	63	56	66	70	75	23
48	53	66	59	69	73	85	23
50	55	70	62	71	75	85	25
53	58	73	65	78	83	85	25
55	60	75	67	80	85	85	25
58	63	78	70	83	88	85	25
60	65	80	72	85	90	95	25
63	68	83	75	88	93	95	25
65	70	85	77	90	95	95	25
68	73	90	81	93	98	95	28
70	75	92	83	99	104	95	28
75	80	97	88	104	109	105	28
80	85	105	95	109	114	105	28
85	90	110	100	114	119	105	28
90	95	115	105	119	124	105	28
95	100	120	110	124	129	105	28
100	105	125	115	129	134	105	28
