814.AWL-05(1677M)

Categories: Allweiler, Brands, O.E.M.Seals, Pumps, Vulcan Replacement

Type：	Suit Allweiler Pumps
Replacement：	Vulcan 1677M
Temperature：	-40 to +200℃
Pressure：	≤2.5Mpa
Speed：	≤15m/s
Material：	B,A1,Q1,Q2,U2,P,E,N,V,F,G,Alfa

Product descripton

d(mm)	D1	D2	D3	L	L1	L2
14	25	21	24	35.0	25.0	10.0
16	27	23	26	35.0	25.0	10.0
18	33	27	32	37.5	26.0	11.5
20	35	29	34	37.5	26.0	11.5
22	37	31	36	37.5	26.0	11.5
24	39	33	38	40.0	28.5	11.5
25	40	34	39	40.0	28.5	11.5
28	43	37	42	42.5	31.0	11.5
30	45	39	44	42.5	31.0	11.5
32	48	42	46	42.5	31.0	11.5
33	48	42	47	42.5	31.0	11.5
35	50	44	49	42.5	31.0	11.5
38	56	49	54	45.0	31.0	14.0
40	58	51	56	45.0	31.0	14.0
43	61	54	59	45.0	31.0	14.0
45	63	56	61	45.0	31.0	14.0
48	66	59	64	45.0	31.0	14.0
50	70	62	66	47.5	32.5	15.0
53	73	65	69	47.5	32.5	15.0
55	75	67	71	47.5	32.5	15.0
58	78	70	78	52.5	37.5	15.0
60	80	72	80	52.5	37.5	15.0
63	83	75	83	52.5	37.5	15.0
65	85	77	85	52.5	37.5	15.0
68	90	81	88	52.5	34.5	18.0
70	92	83	90	60.0	42.0	18.0
75	97	88	99	60.0	42.0	18.0
80	105	95	104	60.0	41.8	18.2
85	110	100	109	60.0	41.8	18.2
90	115	105	114	65.0	46.8	18.2
95	120	110	119	65.0	47.8	17.2
100	125	115	124	65.0	47.8	17.2
